This 24v Solenoid valve is a liquid or gas flow control device. An electrical current is used to regulate the water solenoid valve, which is passed through a coil. The automation of fluid and gas control is feasible thanks to the Air Solenoid valve. Modern solenoid valves have a small design and offer rapid operation, great dependability, and long service life.
Features And Specifications Of 24v 1/4 Inch Electric Solenoid Valve for Air Water/Replacement Brass Valve:
- High-quality replacement part for use with pipelines in water, air, and diesel applications
- Acting Motion: Direct action
- Medium: Air, water, diesel
- Operating Type: Directly driven
- State: Normally closed
- Supply Voltage: 24v
- Pipe Size: 1/4″
- Operating Pressure: 0kg/cm2 – 10kg/cm2
- Fluid Temperature: -5-80 Degree
- CV: 24v DC
- Operating Viscosity: Under 20CST
- Installation: Fluid direction should be as the arrow shows
- Valve Body: Brass
- Oil Seal Material: NBR
Package Includes:
- 1 x 1/4 Inch hole sized solenoid valve
