2 Channel 2x 51K XH M190 Audio Amplifier Board TDA3116D2

Condition: New
Availability: In Stock
Share:     Faceook Twitter

SKU: 637718989490423745

Rs.3200 Rs. 4000

Digital amplifier board has a higher overload capacity than the analogue amplifier, and it won't cause crossover distortion, This is an audio power amplifier board that strengthens low-power, inaudible electronic audio signals such as the signal from radio receiver or electric guitar pickup to a level that is strong enough for driving loudspeakers or headphones. Power amplifiers make the signal audible to listeners. This audio amp board is the final electronic stage in a typical audio playback chain before the signal is sent to the loudspeakers and speaker enclosures.

Features Of Digital Auto Dual Channel Amplifier Module Stereo AMP 12V-24V TDA3116:

  • XH-M190 2*100W digital amplifier board 12V-24V wide voltage TPA3116 dual channel amplifier board.
  • Using a wide DC voltage.
  • Digital IC high resolution.
  • High efficiency and low heat.
  • 100W * 2 superpower.
  • Proposed power supply DC 12-24V 100 or more switching power supply. This board is a finished board, a received can be used.
  • Using two new imports TPA3116 amplification chip, combined with nano-technology, in the field of digital power amplifier ahead.
  • Clear sound, strong amplification function, high efficiency, high-frequency response density.

Specifications Of High-Power 2.0 Channel Mono Audio Amplifier Board 12-24V 100Wx2:

  1. Chip: TPA3116
  2. input voltage: DC12-24V
  3. Output Power: 2*100W
  4. Input resistance: 51K*2
  5. Output matching: 4-8 ohm
  6. Frequency Range: 14-100Kz
  7. SNR: 100db
  8. Output Track: 2(left/right channel)
  9. Product size: approx. 105*65*23mm/4.13*2.55*0.9”
  10. Net weight: approx. 85g

Package Includes:

  • 1 x Digital Amplifier Board
  • 4 x Screws
