ECG Electrodes with Metal Snap and Low Impedance Solid Medical Conductive Gel

Key Specifications/Special Features:

• Description:
• • Disposable ECG electrodes are used for diagnostic ECG or ECG monitoring
  • They can be used for various ECG tests
  • Chunfeng and reg; Disposable ECG electrodes use an AG/AgClsensor element and solid conductive and adhesive Hydro-gel for adhesion
  • The AG/AgCl sensor element has the best sensitivities and the solid conductive and adhesive hydro-gel has very low impedance and is non-irritating, non-sensitizing and non-cytotoxic to the skin
  • All electrodes are latex free
• Components:
• • Metal snap, AG/AgCI sensor, low impedance solid medial conductive gel, white or original color PE foam tape or cloth tape with medical hypoallergenic adhesive, white PE tape indicated brandmark, PET anti-sticking film
• Parameters:
• • Metal snap: stainless steel stud; thickness: 0.6 mm
  • Base PE foam: thickness 1.0mm, density for about60kg/m3
  • Base cloth: weight for about 60G/m2
  • Label dimensions: diameter 32mm or 20 to 25mm width
  • PET anti-sticking film: thickness: 0.075mm; 55mm width
• Characteristics:
• • Superior electrical performance and distinctive ECG presentations
  • Convenient, comfortable, no allergic, no remainder of gel
  • Non-dry up electric conduction gel can be stored for a long time
  • The term of validity: two years
  • Inner packing: 10pcs/bag, 50pcs/aluminum foil and paper pouch
  • Outer packing: 1,000pcs/carton or 2,000pcs/carton, 1,180pcscarton/20ft
  • We design and manufacture a full line of high-quality ECG electrodes and medical sensors We specialize in producing ECG electrodes in various shapes, sizes and material to meet the different needs of our valuable customers
  • We also offer private label programs or OEM for a wide variety of products
  • We may make any of various shapes by the customer requirements

Package Includes:

1x ECG (EMG) PAD
