SKU: 637738985397139132
Rs.4000
Rs. 5000
A 5v switched-mode power supply (SMPS) is an electronic circuit that converts power using switching devices that are turned on and off at high frequencies, and storage components such as inductors or capacitors to supply power when the switching device is in its non-conduction state. A switched-mode power supply is also known as a switch-mode power supply or switching-mode power supply.
Features Of 5V Switching Dc Power Supply:
- The SMPS supplies 5V power for Home & Industrial Appliances.
- AC input selectable by switch
- Cooling by free air convection
- Low cost, high reliability
- Protections:short circuit/overload/over voltage
- 100% full load burn-in test
- It recovers automatically after protection
- The device is great for Home Appliances as a switching power supply.
- It has a built-in EMI filter and improved signal precision.
Specifications Of 5V 200W SMPS For LED lighting:
- Model Number: T-200-5
- Power Type: Constant voltage
- Material: aluminum
- Output Current: 40A
- Output Frequency: 50/60HZ
- Output Type: Triple
- Output Power: 200W
- Output Voltage: 5v
- Input Voltage: 110/220v
- Power Factor: <85%
- Protected Functions: Short circuit/Overload/Over temperature
- Usage: Indoor use
Applications Of LED SMPS 5v 200w :
- LED Lighting
- RGB LED Strip
- SMD
- CCTV Cameras
- Street Light
- Lawn Lamp
- Advertising Article Screen
Note:
- IN-DOOR USE ONLY!
- External power supply round hole meshes heat vents, in the range of 20 inches within the outlet Do not place other flammable items.
- Within 2 inches the product range does not place other items, to ensure that the power supply has a good thermal environment, to ensure safety.
- Please accurately calculate the load power, do not overload. When the power is working, do not touch the case.
- Do not short-circuit output if no output, please use off one minute re-energized.
- Before electricity use, carefully verify the power link is correct, rigorous power lines reversed.
- The professional installation of qualified electricians is highly recommended.
Package Include:
1x Switching Power Supply SMPS 5V 200W 40A
