STM32 by ST NUCLEO-F756 STM32 Nucleo-144 Development Board with STM32F756 MCU

Condition: New
Availability: Out Of Stock
Share:     Faceook Twitter

SKU: 637724990920651349

Rs.7200 Rs. 9000

The STM32 Nucleo-144 board provides an affordable and flexible way for users to try out new concepts and build prototypes with the STM32 microcontroller, choosing from the various combinations of performance, power consumption, and features. The ST Zio connector, which is an extension of Arduino isUno, provides access to more peripherals and ST Morpho headers make it easy to expand the functionality of the Nucleo open development platform with a wide choice of specialized shields. The STM32 Nucleo-144 board does not require any separate probe, as it integrates the ST-LINK/V2-1 debugger/programmer

Features:
  1. Arm cortex-M7 core at 216 MHz
  2. 1 mbyte of flash memory, 320 kbytes of SRAM
  3. Two extension types:
  4. ST zio connector including support for Arduino Uno V3
  5. ST morpho extension pin header footprints for full access to all STM32 I/Os
  6. Ethernet 10/100 Mbps
  7. USB OTG user connectivity
  8. Embedded ST-LINK/V2-1 debugger/programmer
  9. mbed-enabled
System Requirments:
  1. Windows OS ( 7,8 and 10), Linux 64 bit or macOS
  2. USB type A to Micro B cable
Package Include:

1XSTM32 by ST NUCLEO-F756 STM32 Nucleo-144 Development Board with STM32F756 MCU
