A 12v switched-mode power supply (SMPS) is an electronic circuit that converts power using switching devices that are turned on and off at high frequencies, and storage components such as inductors or capacitors to supply power when the switching device is in its non-conduction state. A switched-mode power supply is also known as a switch-mode power supply or switching-mode power supply. The 12V 5A SMPS Adapter is made of High-temperature resistant copper enameled wire and adopts a double winding U-shaped iron core, which has a strong anti-interference ability and high stability.5A Switching Power supply For
- LED Lighting has High intelligent protection with short circuit protection, overload protection, and overvoltage protection
- Good anti-interference performance and high reliability.
- Low operating temperature and long service life.
- Wide input voltage range, (100-240V) in line with global usage standards.
- Good insulation performance and high electric strength.
- Full load high temperature burning machine, 100% aging test.
- Protection function: Overload protection, Short circuit protection
- It recovers automatically after protection
- The device is great for Home Appliances as a switching power supply.
- Input voltage: 110V-220V AC
- Output voltage: 12V DC
- Output current: 5A
- Output power: 60W
- Protection function: Overload protection, Short circuit protection
- Security Certification: CE, ROHS, FCC
- Working Humidity and Temperature: -20 ° C - +60 ° C, 20% - 90% RH
- Product dimension: 87.5 x 57.5 x 37.5mm
- LED Lighting
- RGB LED Strip
- SMD
- CCTV Cameras
- Street Light
- Lawn Lamp
- Advertising Article Screen
- The power supply is 100% full, but some power is lost when wiring. Therefore, it is recommended to use 80-85% of the power.
- The input voltage should be within the specified working range.
- It is strictly forbidden to use in a high-temperature environment, the power supply should have good heat dissipation space and environment.
- Do not install the power supply on flammable materials, keep away from gas stations or places where smoking is prohibited.
- 1x Switching Power Supply SMPS 12V 60W 5A
Features Of 12V 5A Switching Transformer Dc Power Supply:
Specifications Of 12V 60W Switched Mode Transformer SMPS For LED lighting:
Applications Of LED SMPS 12v 60w :
Note:
Package Include:
