Arduino Wifi 101 Shield

Condition: New
Availability: Out Of Stock
Share:     Faceook Twitter

SKU: 637725046648038144

Rs.7500 Rs. 9375

Arduino Wifi 101 Shield is a powerful IoT shield with crypto-authentication.,Arduino Wifi 101 Shield developed with Atmel, that connects your Arduino or Genuino board to the internet wirelessly. Connecting it to a WiFi network is simple, no further configuration in addition to the SSID and the password are required. Arduino Wifi 101 Shield comes with an easy to use library that allows to connect your Arduino or Genuino board to the internet with few instructions.This means that you can learn exactly how it's made and use its design as the starting point for your own projects.

Arduino Wifi 101 Shield Specifications:

  1. Operating voltage both 3.3V and 5V (supplied from the host board)
  2. Connection via: IEEE 802.11 b/g/n for up to 72 Mbps networks
  3. Encryption types: WEP and WPA2 Personal
  4. Support TLS 1.1 (SHA256)
  5. Connection with Arduino or Genuino on SPI port
  6. Onboard CryptoAuthentication by ATMEL

Different Led Indicators:

  1. ON (green) : indicates that the shield is properly powered
  2. WIFI (green) : indicates a connection to a network
  3. ERROR (red) : indicates when there is a communication error
  4. NETWORK (yellow) : indicates that data is received/transmitted

Package Includes:

  • 1 x Arduino Wifi 101 Shield

Based on 1 reviews



Add a review

Abdullah - July 07, 2022
