Modbus Slave RTD Remote I/O Module Data Acquisition 8 RTD inputs 12~36VDC with Anti-reverse Protection M340
SKU: 637739639561647320
The M340 Modbus RTD Remote I/O Module is an industrial class, high reliability, high stability and high precision data acquisition
module, embedded 32-Bit High Performance Microprocessor MCU, provides a RS485 interface. It provides multi I/O, supports
standard Modbus TCP, can be intergraded into SCADA, OPC server, and other automation systems. It is design for working in
the harsh industrial application environment, widely used in a variety of industrial automation, security monitoring system,
automatically measurement and control system
The M340 Modbus RTD Remote I/O module provides 8 RTD inputs, supports PT100 and PT1000 resistance sensor, compatible2 or 3 wires, the resolution is 0.1°C, measure range -120°C ~420°C. All of the I/O with high sampling frequency and specialfiltering strategy to ensure its reliable.The M340 Modbus RTD Remote I/O module can work at 12~36VDC with anti-reverse protection design.
